PROCALC design software
PROCALC design software
Click here to download
PROCALC is a very useful tool for structural engineers, saving the need for long hand calculations and offering anchoring solutions for various substrates developed by experts in the fixing industry, with the Europe design standards (ETAG) as a base of calculation.
PROCALC has a user friendly interface, covering a large range of concrete classes, with all shapes of metal base plate with predefined groups of holes using standard profiles from the construction metal industry and with a 3D view of the work in real time.
Calculations can be made for all types of situations including uncracked & cracked concrete, seismic C1 or C2 exposure, fire exposure, flooded bore holes, post-installed rebar connections according to EN1992-1, suspended ceiling anchoring, and façade anchoring.
Characteristics:
- Utilisation factor shown in percentage
- Anchor filter option. Cracked / Uncracked concrete
- C2 seismic calculations, flooded holes, non-standard embedment
- Multiple temperature range selection / Lever Arm
- Fixed setting depth options / Concrete Class option
- Post-Installed Rebar / Suspended Ceiling / Facade module
- 3D GUI with intuitive plate editor function and real-time updates
- Live updates for codification changes, or anchor data changes
- Built-in help module and instruction database
- Full PDF Anchor Calculation Report in long or short version
To download and install PROCALC software, please follow the instructions below:
1. Download PROCALC zip file from dropbox.
2. Select 'Save' and install file on local computer.
3. Click the executable (.exe) file contained within the downloaded zip file.
4. Allow the program to makes changes to local computer.
5. Follow PRO CALC setup guidance to install software on local computer.
Open software and start calculating :-
